The TC2300 PCIe® Gen 5x4 4CH DRAMless 12GB/s
The TenaFe TC2300 is an industry-leading PCIe® Gen 5 NVMe™ SSD controller, delivering impressive performance with speeds of up to 12GB/s. This DRAMless controller features 4 channels operating at 3600 MT/s.
APPLICATIONS
Designed for a Wide Range of High-Performance Client Applications
Enterprise Storage Systems
Corporate Professional Applications
Server Applications
OVERVIEW
TC2200 VS TC2300 Gen5
Performance
I/O Speed
TC2200 Gen4
TC2300 Gen5
50%Up
50%Up
Optimized for high-performance client applications for workstations and gaming platforms, with sequential speeds up to 12 GB/s.
Built on the TSMC 6nm process and with power consumption of less than 2.5W.
FEATURES
Our SSD controller supports Host Memory Buffer (HMB) technology, enabling high-performance operation without the need for onboard DRAM. By utilizing a small portion of the host system’s memory, the controller efficiently manages flash operations and accelerates access speeds in DRAMless configurations. With built-in SECDED protection, HMB ensures reliable data handling and enhanced system integrity—making it ideal for cost-effective, power-efficient SSD solutions without compromising performance.
Host Memory Buffer
The TenaFe TC2300 SSD controller is engineered to ensure exceptional data integrity, making it ideal for enterprise and data center applications. With features like end-to-end data protection, CRC error detection, SRAM SECDED protection, 4KB LDPC ECC, and RAID configurations, the TC2300 guarantees reliable and accurate data storage and retrieval. These advanced capabilities safeguard against data corruption and hardware failures, ensuring your critical data remains secure and dependable.
Data Integrity
The TenaFe TC2300 SSD controller boasts a robust architecture designed for high performance and flexibility. It supports PCIe Gen5x4 and Gen5x2 interfaces, and features an 8-channel NAND Flash interface with speeds up to 3,600 MT/s. The controller is equipped with 8 RISC-V main CPUs and supports both DDR4 and DDR5 DRAM architectures. Notably, the TC2300 can operate in a DRAMless configuration using Host Memory Buffer (HMB) support, which reduces costs and power consumption while maintaining high performance and reliability. This makes it an excellent choice for enterprise and data center applications.
DRAMless
SPECIFICATIONS
Interface
Flash
DRAM
Performance
Power
Security
• 4CH @ 3600 MT/s
• NAND Flash Support TLC & QLC
• PCIe® Gen 5 x 4
• NVMe™ 2.0
• Sequential up to 12 GB/s
• Supports up to 8TB
• DRAMless
• Support HMB
• Inline AES-256, ECB
• Support TCG Standards
• FIPs 140-3 capable
• Secure Boot/Firmware Update
• < 4.3 SSD Active Power
• < 4.9W SSD Active Power
Data Integrity
• End-to-end data protection
• SRAM SECDED protection
• Advanced 4KB LDPC
• Plane-based/Die-based RAID
